Abstract
Gastric pacing has shown preclinical success in modulating bioelectrical slow-wave activity and has potential as a novel therapy for functional motility disorders. However, the translation of pacing techniques to the small intestine remains preliminary. This paper presents the first high-resolution framework for simultaneous pacing and response mapping of the small intestine. A novel surface-contact electrode array, capable of simultaneous pacing and high-resolution mapping of the pacing response, was developed and applied in vivo on the proximal jejunum of pigs. Pacing parameters including the input energy and pacing electrode orientation were systematically evaluated, and the efficacy of pacing was determined by analyzing spatiotemporal characteristics of entrained slow waves. Histological analysis was conducted to determine if the pacing resulted in tissue damage. A total of 54 studies were conducted on 11 pigs, and pacemaker propagation patterns were successfully achieved at both low (2 mA, 50 ms) and high (4 mA, 100 ms) energy levels with the pacing electrodes oriented in the antegrade, retrograde, and circumferential directions. The high energy level performed significantly better (
= 0.014) in achieving spatial entrainment. Comparable success (greater than 70%) was achieved when pacing in the circumferential and antegrade pacing directions, and no tissue damage was observed at the pacing sites. This study defined the spatial response of small intestine pacing in vivo revealing effective pacing parameters for slow-wave entrainment in the jejunum. Intestinal pacing now awaits translation to restore disordered slow-wave activity associated with motility disorders.
A novel surface-contact electrode array customized for the small intestine anatomy enabled simultaneous pacing and high-resolution response mapping. The spatial response of small intestine bioelectrical activity to pacing was mapped for the first time in vivo. Antegrade and circumferential pacing achieved spatial entrainment over 70% of the time and their induced pattern was held for 4-6 cycles postpacing at high energy (4 mA, 100 ms, at ∼2.7 s which corresponds to 1.1 × intrinsic frequency).
